Juniper Power Supplies & Fans for EX Switches
According to Juniper, EX4100, EX4400 and EX4650 switches feature redundant hot-swappable power supplies and field-replaceable fans. Additional power supplies increase availability and, on PoE models, the available PoE budget.
Power supplies and fans are available with front-to-back or back-to-front airflow and in some cases as DC versions. The airflow direction must match the device and the rack ventilation. According to the datasheet, Juniper covers EX Series power supplies and fan trays under warranty for five years.
We are happy to advise you on project and volume enquiries. On request, DEVACON takes care of planning, configuration and commissioning.
Key facts from the Juniper datasheet
- Hot-swappable power supplies, redundant operation possible
- EX4100: 150 W AC/DC and 920 W AC
- EX4400: 550 W AC/DC, 1050 W, 1600 W and 2000 W AC
- EX4650: 650 W AC/DC
- Field-replaceable fans, front-to-back or back-to-front airflow
- Power cords for EX4400 power supplies to be ordered separately
- Warranty for EX Series power supplies and fan trays: five years
Areas of use
- Redundant power
- Higher PoE budget on PoE switches
- Spare parts stock
Models and key specifications
| Part number | Series | Description |
|---|---|---|
| JPSU-150-AC-AFO | EX4100 | 150 W AC, front-to-back airflow |
| JPSU-150-AC-AFI | EX4100 | 150 W AC, back-to-front airflow |
| JPSU-150-DC-AFO | EX4100 | 150 W DC, front-to-back airflow |
| JPSU-920-AC-AFO | EX4100 | 920 W AC, front-to-back airflow |
| EX4100-FAN-AFO | EX4100 | Spare fan, front-to-back |
| EX4100-FAN-AFI | EX4100 | Spare fan, back-to-front |
| JPSU-550-C-AC-AFO | EX4400 | 550 W AC, front-to-back |
| JPSU-550-C-AC-AFI | EX4400 | 550 W AC, back-to-front |
| JPSU-550-C-DC-AFO | EX4400 | 550 W DC, front-to-back |
| JPSU-550-C-DC-AFI | EX4400 | 550 W DC, back-to-front |
| JPSU-1050-C-AC-AFO | EX4400 | 1050 W AC, front-to-back |
| JPSU-1600-C-AC-AFO | EX4400 | 1600 W AC, front-to-back |
| JPSU-2000-C-AC-AFO | EX4400 | 2000 W AC, front-to-back |
| EX4400-FAN | EX4400 | Spare fan, front-to-back |
| EX4400-FAN-AFI | EX4400 | Spare fan, back-to-front |
| JPSU-650W-AC-AFO | EX4650 | 650 W AC, port-side to FRU-side airflow |
| JPSU-650W-AC-AFI | EX4650 | 650 W AC, FRU-side to port-side airflow |
| JPSU-650W-DC-AFO | EX4650 | 650 W DC, port-side to FRU-side airflow |
| JPSU-650W-DC-AFI | EX4650 | 650 W DC, FRU-side to port-side airflow |
| QFX5110-FANAFO | EX4650 | Fan module, front-to-back |
| QFX5110-FANAFI | EX4650 | Fan module, back-to-front |
Part numbers from the ordering information of the Juniper datasheets EX4100 (Jan 2023), EX4400 (Sept 2024) and EX4650 (July 2023). JPSU-2000-C-AC-AFO is listed in table 2 (spare chassis) of the EX4400 datasheet. We clarify which power rating applies to which model during consultation.
Source of information: juniper.net EX4400 Datenblatt (PDF) ·juniper.net EX4100 Datenblatt (PDF) ·juniper.net EX4650 Datenblatt (PDF) ·Juniper Hardware Compatibility Tool
