Juniper EX2300 Ethernet Switch
The Juniper EX2300 Ethernet Switch is a compact and reliable solution for modern business networks. The model is ideal for smaller sites, branches, offices and access environments that require stable switching, simple management and professional network integration.
Combined with DEVACON consulting, you get a tailored solution for new networks, site expansions or modernisation projects.
Key facts from the Juniper datasheet
- Form factor: 1 U
- Virtual Chassis with up to 4 switches, 80 Gbps
- PoE (802.3af) and PoE+ (802.3at), system budget up to 750 W
- Integrated power supply and fans
- Throughput 95 Mpps (24-port) or 130 Mpps (48-port)
- Cloud management with Juniper Mist Wired Assurance
Models and key specifications
| Model | Access ports | Uplinks | PoE budget | Switching capacity |
|---|---|---|---|---|
| EX2300-24T | 24 × 1 GbE RJ45 | 4 × 1/10 GbE SFP+ | no PoE | 128 Gbit/s |
| EX2300-24P | 24 × 1 GbE RJ45 PoE+ | 4 × 1/10 GbE SFP+ | 370 W | 128 Gbit/s |
| EX2300-24MP | 8 × 2.5 GbE + 16 × 1 GbE PoE+ | 4 × 1/10 GbE SFP+ | 380 W | 152 Gbit/s |
| EX2300-48T | 48 × 1 GbE RJ45 | 4 × 1/10 GbE SFP+ | no PoE | 176 Gbit/s |
| EX2300-48P | 48 × 1 GbE RJ45 PoE+ | 4 × 1/10 GbE SFP+ | 750 W | 176 Gbit/s |
| EX2300-48MP | 16 × 2.5 GbE + 32 × 1 GbE PoE+ | 6 × 1/10 GbE SFP+ | 750 W | 264 Gbit/s |
Switching capacity bidirectional. Uplinks usable as Virtual Chassis ports (VC license required). EX2300-C (12 ports, compact) has its own datasheet and is not included here.
Source of information: juniper.net (PDF) ·juniper.net ·hpe.com
